Section 1







                                                Mercruiser

                                 Exploded Views, Gaskets


                                            & Components                                                          Mercruiser Manifold Line


                        Inline 4 - 181 CID (1990 & Up) ....................................................6-7
                        Inline 4 - 153/181 CID (1982-95) .................................................8-9
                        Inline 4 - 181 CID (1968-82) ....................................................10-11
                        Inline 4 - 244 CID (1980-89) ................................................... 12-13
                        Inline 4 - 224 CID (1976-82) ................................................... 14-15
                        V6/V8 Exhaust Manifold Dimensions with 3”  & 4” Risers ....... 16-17
                        V6/V8 S.B. Dry Joint & “Alternative” Manifold Dimensions..... 18-19

                        V6 - 229/262 CID (1983 up to 0M SN#’s) ............................... 20-21
                        V6 - 229/262 CID (1983 up to 0M SN#’s) Combinations ..............22
                        Complete Manifold Kits - GM V6..................................................23
                        Complete Manifold Conversion Kit - GM V6 ................................24
                        Complete Manifold Dry Joint & D.J. “Alternative” Kits - GM V6 ....25
                        V6 & V8 S.B. Dry Joint (2005 & Up) ....................................... 26-27
                        V6 & V8 S.B. Dry Joint “Alternative” (0M SN#’s & Up) ............ 28-29

                        V8 - 305/350/377 CID (1983 up to 0M SN#’s) ........................ 30-31
                        V8 S.B. - 305/350 CID (1977-82)............................................ 32-33
                        V8 - 305/350/377 CID Combinations (1983 up to 0M SN#’s) .......34
                        Complete Manifold Kits / Conversion Kit - GM V8 S. B. ......... 35-36
                        Complete Manifold Dry Joint & D.J. “Alternative” Kits - V8 S.B. ...37
                        V8 B.B - 454/502 CID (1981 & Up) ......................................... 38-39
                        V8 B.B - 454/502 CID Combinations (1981 & Up)........................40
                        Complete Exhaust Manifold Kits - GM V8 B.B. ............................41
                        Complete Conversion Kit w/ 460 Adapter Plates - V8 B.B. ...........42

                        Exhaust Flapper Valves, Water Shutters & Exhaust Bellows ........43
                        Spacer Kits & Spacers - Standard Cooling & Dry Joint “Alternative” ... 44
                        Spacer Kits & Exhaust Elbow Gaskets - Dry Joint Cooling ...........45
                        Exhaust Gasket Sets ....................................................................46  Section 1
                        Exhaust Manifold Mounting Kits, Gaskets & Adapter Plate ..........47
                        Exhaust Elbow Mounting Kits, Gaskets, End Caps................. 48-49
                        GLM Manifold Applications for Mercruiser ............................. 50-53

                        GLM V8 S.B. / V8 B.B. Exhaust System Evaluation ............... 54-56
